Smart Key System Diagnostic Online Course

Smart Key System Diagnostic in KIA & Hyundai Vehicles

Course Instructor

Mechanicourse Author

Smart Key System Diagnostic Course Information:

Smart Key System Diagnostic Course Includes:

• 2.5 Hours On-Demand Video
• Full Lifetime Access
• Hands-on practical lessons
• Presented by Dealerships Master Technicians
• Extensive information on wiring diagrams.
• Diagnostic with scan tool.
• Certificate of Completion (After Watching each lecture, please mark the video as “Completed” to get the certificate of completion after completing all videos.
• Any question about this course? Let us know: Training@Mechanicourse.com

Course Introduction

Course Description

This course covers everything about Smart Key System Diagnostic (Push Button Start) on Hyundai and KIA Vehicles.

KIA and Hyundai started using smart key system before 2010. Comparing to common immobilizer systems, smart key system provides much more features, but at the same time it is more complex as well.

There are many components used on smart key systems, and each one of them can cause an issue, so understanding the system and components operation is very necessary. In this course, we explain each single component one by one, for location, operation, wiring diagram and diagnostic.

There has been some changes on smart key system on Hyundai and Kia vehicles over the years, and these changes can make the smart key system diagnostic a little complicated, so in this course we explain every changes and differences, and we show you all that on the wiring diagrams too.

Not only all components diagnostics are explained and the wiring diagrams for each generations are explained, but also the diagnostic procedure using a scan tool is shown too. We show you how to test the smart key system with scan tool, and how neutralize and how to program the keys.

Here is the list of components and features covered in this course:

– Start Stop Button

– Smart Key

– Smart Key Holder

– Smart Key Control Module

– Power Distribution Control Module (PDM)

– Electric Steering Column Lock (ESCL)

– Low Frequency antennas

– RF (Radio Frequency) Receiver

– Smart Key warning Messages

– Smart Key wiring Diagrams

– Smart Key Diagnostic with scan tool

– Common fault codes diagnostic procedure

By the end of this course you will:

– Be able to identify and locate all component of smart key system on any Hyundai & KIA vehicle.

– Be able to explain the smart key system operation.

– Be able to read and analyze the smart key system wiring diagram.

– Be able to identify the different generation of smart key system.

– Be able to diagnose the smart key system.

– Be able to test the smart key system using a scan tool and program the keys.

– Be able to understand the smart key system warning messages.

Downloadable Materials

FAQs

Q: Can I learn Smart Key System diagnostic online?
A: Yes. This course teaches everything from basics to advanced diagnostic of Smart Key systems. We explain how this systems works, then all components will be explained one by one. After understanding each single components, we explain the diagnostic on real cars using real diagnostic equipment.

Q: How long does the Smart Key System Diagnostic course take?
A: Approximately 2.5 hours of video content, but you have lifetime access.

Q: Do you explain the wiring diagrams of this system too?
A: Yes, wiring diagrams are very important for Smart Key system diagnostic. Not only we explain the diagrams, but also we use them for identifying the wires on the car and for diagnostic as well.

Q: Is this course useful for beginners too?
A: Yes. Our approach is to provide in depth training which is very helpful for all skill levels.

Q: What is the difference between Smart Key System and Push Button Starting System? Are they the same or different?
A: Smart Key system is also sometimes called Push Button Starting system which refers only to the main relevant change on this system, but push button is not the only part of the anti-theft system changed, there are many more components working together to enhance the operation of this system, that is why it’s called smart key system.
